Aluminum Foil Roll Packing Machine Electric PLC Automatic Easy Operate Multi-Function
5.0
design customization
Please fill out the form below to request a quote or to request more information about us. Please be sure to upload customized requirement documents or pictures, and we will get back to you as soon as possible with a response. we're ready to start working on your new project, contact us now to get started.
Please fill out the form below to request a quote or to request more information about us. please be as detailed as possible in your message, and we will get back to you as soon as possible with a response. we're ready to start working on your new project, contact us now to get started.
machine introduction
The Aluminum Foil Roll Packing Machine is an electric, PLC-controlled automatic packaging solution engineered specifically for small aluminum foil rolls and similar rolled products. This multi-function unit integrates a complete packaging workflow — automatic feeding, box erecting, product loading, adhesive spraying, carton sealing, and rejected waste discharge — into a streamlined system.
Powered by a programmable logic controller (PLC) and a high-sensitivity touch screen interface, the machine delivers precise braking control and an intuitive operator experience. A built-in photoelectric detection and tracking system actively identifies empty packages and prevents them from reaching the carton sealing stage, maximizing the utilization of packaging materials.
Application Scenario
Aluminum Foil Conversion Lines
At the end of slitting or rewinding lines, the machine automatically boxes small foil rolls immediately after production, eliminating manual collection and sorting.
Food Service Foil Packaging
Ideal for catering supply companies that package small aluminum foil rolls for restaurants, bakeries, and food trucks, ensuring fast and hygienic carton sealing.
Restaurant Kitchen
Streamline the packaging process of aluminum foil rolls in restaurant kitchens with automatic continuous sealing.
Third-Party Contract Packaging
Perfect for contract packaging service providers who handle aluminum foil rolls or similar rolled products for multiple brands, offering quick changeover and multi-function capability.
Product Display
machine operation
RELATED machine operation
×
Semi-automatic rewinding machine
We offer both semi-automatic and fully automatic rewinding machines. The semi-automatic model is a 2-shaft machine for rewinding aluminum foil and baking paper rolls with manual gluing. The fully automatic model is a 6-shaft machine for rewinding aluminum foil, baking paper, and cling film, equipped with an automatic gluing system and automatic stop-alarm functions for short label pasting, film breakage, and paper tube shortage.
×
Aluminum foil pop up sheets machine
High Speed Aluminum Foil Household Pop-up Sheet Folding Making Machine is a professional inter-folded foil sheet machine.This machine works on the Pre-Cut, Interfold, Pop Up Foil Sheet of Aluminum Foil. It can connect with the automatic sheets box packing machine to be a full automatic production line. The full production line includes the bump and alufoil sheet pop out machine. Production processing : Material feeding ➤ inter folding ➤forming & counting ➤packing Function * 2 “V”/3 “Z” folding machine can be customized * 680mm ~ 1200mm machine can be customized * 400~500 pcs/row working speed * Automatic counting divided into output in line * Support different embossing pattern design
FAQ
1
What is the actual packing speed of this machine?
The standard operating speed is 30-60 boxes per minute, depending on carton size and material characteristics. The speed is adjustable via the touch screen.
2
What are the requirements for the carton material?
It is recommended to use 300g/m² or 400g/m² white cardboard to ensure stable box erecting and glue sealing performance.
3
What is the carton size range that this machine can handle?
The carton size range is: Length 200-460mm × Width 30-60mm × Height 30-60mm. Custom solutions are available for sizes outside this range.
4
Does the machine require an external air supply? What is the working air pressure?
Yes. The required working air pressure is 0.6-0.9 Mpa, with an air consumption of less than 5m³/h.
5
What are the power requirements and total motor power?
The power supply is 380V, 3-phase, 50Hz AC. The total motor power is 5KW.
6
What is the floor space required for this machine?
The machine dimensions are 4100mm (L) × 1600mm (W) × 1900mm (H), with a weight of approximately 1800KG. Additional space for maintenance access is recommended.
